Wall-rack fit finder
Measure the tires before choosing the rack
The best wall-mounted tire racks for four tires are the ones that fit the complete set within their adjustable width, keep its combined weight below the total listed capacity, and let both wall brackets fasten directly to suitable wood studs.
Measure four tires side by side
Measure the set at its widest sidewall bulges. Do not rely only on the nominal tire size or the rack’s marketing photo.
Weigh the complete set
Add the actual weight of all four tires and any wheels. Treat the rack rating as a total evenly distributed load, not a per-tire rating.
Map studs and clearances
Confirm the bracket locations can reach wood framing and that the loaded rack clears the garage door, tracks, vehicle, people, and cabinets.
Quick answer: The HyLoft 01012 is the simplest fit for a typical four-tire set measuring 36 to 48 inches across. Choose the 01031 Folding TireLoft when you want the empty rack to fold against the wall, or the 01000 Heavy-Duty TireLoft when the set needs more than 48 inches of width or a higher listed capacity. All three require direct attachment to wall studs.
First decide whether a wall rack is the correct storage position
Michelin says tires without rims should stand upright; this is the job these tread-supporting wall racks fit best. Michelin says tires mounted on rims should be stacked or hung instead of stored standing upright. If your seasonal tires are already mounted on wheels, read our mounted-versus-unmounted tire-storage guide before buying this style of rack.
Best wall-mounted tire racks by use case
We compared current manufacturer dimensions, load limits, installation instructions, and exact retailer listings. The three designs solve different wall-space and fit problems.
As an Amazon Associate I earn from qualifying purchases. If you purchase through one of these links, Garage Results may earn a commission at no added cost to you.
| Best for | Exact model | Adjustable width | Total listed capacity | Important limit |
|---|---|---|---|---|
| Standard four-tire set | HyLoft 01012 | 36-48 in. | 375 lb. | The set must measure at least 36 inches across; mount directly to studs. |
| Fold-flat empty rack | HyLoft 01031 | 32-48 in. | 300 lb. | Lower load limit; fold it only after removing the tires. |
| Wide or heavier set | HyLoft 01000 | 34-58 in. | 400 lb. | Wider wall footprint; the instructions say not to install more than one rack on any pair of wall studs. |
HyLoft 01012 Adjustable TireLoft
The 01012 covers the middle of the range: its 36-to-48-inch adjustment fits many four-tire passenger sets without requiring the longer wall span of the heavy-duty model.
Verified: 36-48 in. adjustable width; 375 lb. total listed capacity; direct-to-stud installation.
Do not buy it when: your physical four-tire measurement is below 36 inches or above 48 inches, or the bracket locations cannot land on suitable framing.
HyLoft 01031 Folding TireLoft
The 01031 folds toward the wall after the tires are removed. That makes sense in a shared bay or seasonal workspace where the rack would otherwise project into the room while empty.
Verified: 32-48 in. adjustable mounting width; 300 lb. total capacity; four standard tires; direct-to-stud installation.
Do not buy it when: the complete set weighs more than 300 pounds or you need more than 48 inches of tire width. It is not a shortcut around clearance while loaded.
HyLoft 01000 Heavy-Duty TireLoft
The 01000 extends to 58 inches and its support bars adjust in width and depth. It is the appropriate one of these three to measure first for wide truck, track-day, or staggered sets.
Verified: 34-58 in. adjustable width; 400 lb. total capacity; width- and depth-adjustable support tubes; direct-to-stud installation.
Do not buy it when: a 58-inch rack cannot clear doors, tracks, cabinets, vehicles, or walking space. A higher rating does not make weak framing acceptable.
How wide a rack do four tires need?
Use a tape measure on the actual set whenever possible. The first number in a metric tire size is the nominal section width in millimeters, so it can provide an early estimate, but the mounted or unmounted tire’s measured widest point is the final authority.
The estimate is:
For example, four nominal 225 mm tires total roughly 900 mm, or 35.4 inches. That does not guarantee a 36-inch rack will fit: construction tolerances, sidewall shape, wheel width, tire deformation, and the rack’s usable inside space can change the result. Measure the set and leave practical loading clearance rather than forcing the tires between brackets.
Six checks before buying
Installation and wall limits
A wall rack is only as dependable as the framing and fasteners carrying it. The manufacturer’s capacity assumes the correct installation and an evenly distributed load; it does not certify an unknown wall.
- Read the exact model instructions firstConfirm the included parts, tools, bracket spacing, pilot-hole size, fastener sequence, and warranty conditions before drilling.
- Locate utilities as well as studsCheck for electrical wiring, plumbing, and gas lines before drilling. A stud finder is a starting point, not permission to drill blindly.
- Confirm both brackets reach sound framingDo not substitute ordinary drywall anchors for the direct-to-stud installation required by these models. Ask a qualified professional about masonry, metal studs, damaged framing, or a wall you cannot identify.
- Test every clearance through the door cycleMove the garage door fully open and closed and verify the rack, tires, opener rail, tracks, and vehicle do not enter one another’s space.
- Load evenly and stay below the total limitCenter the set, avoid impact loading, and do not treat the listed capacity as a target. Never climb, hang, or suspend other items from the rack unless the manufacturer explicitly permits it.
- Inspect the installation periodicallyLook for loose fasteners, wall damage, corrosion, bending, or movement. The instructions for all three reviewed models call for fasteners or connections to be checked at least annually.
Who should not buy a wall-mounted tire rack?
Your tires are mounted on wheels
Michelin recommends stacking mounted tires or hanging them by the wheel rather than storing them standing upright. Use the broad storage guide to choose the correct method.
You cannot confirm the framing
Drywall alone is not the supporting structure. Do not guess at studs, utilities, masonry fasteners, or metal framing for a rack carrying a heavy set.
The rack would be above a vehicle or doorway
If loading, inspection, or a failure could put people or property in the fall zone, choose a low floor rack or another location.
The set exceeds a dimension or load limit
Do not compress the set into an undersized width or assume a nominal tire size proves fit. Choose a larger suitable system or store the set another way.
Selection guide: which design fits your garage?
Choose the 01012 when four physically measured tires fit between 36 and 48 inches, the total load stays within 375 pounds, and you want a fixed general-purpose rack.
Choose the folding 01031 when the empty rack’s projection matters for part of the year. It has the lowest listed capacity of the group, so confirm both weight and width before valuing the folding feature.
Choose the heavy-duty 01000 when a wider set needs more than 48 inches and no more than 58 inches, or when the complete set exceeds the 01012’s 375-pound limit but remains within 400 pounds. Its larger range also means you must reserve more unobstructed wall space.
Choose none of these when the storage position conflicts with the tire manufacturer’s guidance, the wall cannot provide suitable direct-to-stud attachment, or the loaded rack would interfere with the garage door or create an unsafe lifting task.
For broader planning beyond tire racks, browse our garage storage, floor, and wall guide hub.
Wall-mounted tire rack FAQ
Can a wall rack hold four truck tires?
Possibly, but “four” is not enough information. Measure the actual set width and total weight, then compare both with the rack’s range and capacity. Large truck tires may also project farther from the wall and be unsafe to lift to the planned height.
Is the listed capacity per tire or for the whole rack?
For the reviewed HyLoft models, it is the total rack capacity with the load evenly distributed. Add all four tires and any wheels; do not multiply the rating by four.
Can I install one of these with drywall anchors?
No. The reviewed manufacturer instructions require direct attachment to wall studs. Drywall is a finish surface, not the framing assumed by the listed capacity.
Can I mount a rack to concrete or metal studs?
The reviewed instructions are written for wall studs and supplied hardware. Do not invent an alternate anchoring method from the load rating. Ask the manufacturer or a qualified professional for a method approved for the actual wall.
How high should a tire rack be mounted?
There is no universal height. Keep it high enough to recover useful floor space but low enough to load each tire with controlled posture and without lifting over a vehicle. Preserve the clearances and mounting positions in the exact instructions.
Can the HyLoft 01031 fold while tires are on it?
No. The folding feature is for reducing the empty rack’s projection. Remove the load before folding it toward the wall.
How we researched this guide
Garage Results compared the current manufacturer catalog, model-specific installation sheets, tire-storage guidance, and retailer model identifiers. Recheck the exact product, wall requirements, seller, and availability before purchase.
